What Is Colloidal Gold Immunoassay? The Science Behind Rapid Diagnostic Tests
Colloidal gold immunoassay — also called lateral flow immunoassay (LFIA) or immunochromatographic strip (ICS) testing — is the core technology inside every Sabervet rapid diagnostic test kit. Understanding how it works explains why veterinarians and farm managers across more than 40 countries rely on these tests for fast, reliable point-of-care diagnosis in dogs, cats, pigs, cattle and poultry.
The principle is elegant: colloidal gold nanoparticles (typically 20–40 nm in diameter) are conjugated to specific antibodies or antigens. When a patient sample migrates along a nitrocellulose membrane, target molecules in the sample bind to the labelled conjugate, producing a visually distinct red or pink line within minutes — no laboratory equipment required.
Lateral Flow Immunoassay (LFIA): Core Components and How They Work
Every LFIA test strip shares the same architecture regardless of target disease or animal species. There are four key functional zones:
- Sample pad: Receives the raw sample (whole blood, serum, plasma, swab eluate, faeces or urine). Pre-treatment reagents here filter particulates and adjust pH for optimal migration.
- Conjugate pad: Contains the dried colloidal gold–antibody (or antigen) conjugate. When the sample rehydrates this pad, conjugate is released and binds to any target analyte present in the sample.
- Nitrocellulose membrane: The reaction zone. Two capture lines are immobilised here: the test line (T), which captures the target–conjugate complex, and the control line (C), which captures excess conjugate to confirm the test is valid. Coloured lines form wherever gold conjugate accumulates.
- Absorbent pad: Downstream wicking pad that maintains fluid flow and prevents backflow.
Reading the Result
- Positive: Both T line and C line appear.
- Negative: Only C line appears.
- Invalid: No C line — test must be repeated with a new cassette.
A faint T line is always positive regardless of intensity. Results are read at the time specified on the package insert (typically 5–15 minutes depending on the test). Reading after the specified window may produce false results.
Competitive vs. Sandwich Format
Sabervet antigen (Ag) tests typically use the sandwich format: two antibodies targeting different epitopes of the same antigen flank the target, producing a T line when antigen is present. This format offers high sensitivity for direct pathogen detection.
Sabervet antibody (Ab) tests typically use the competitive or indirect format: antigen is immobilised at the T line, and patient antibodies compete with or bind to the gold-labelled secondary antibody. This format is optimised for IgG/IgM serodiagnosis.
Sabervet Rapid Tests by Animal Species
Canine Rapid Tests
The Sabervet canine range covers the most clinically significant infectious diseases in dogs. All tests accept whole blood, serum or plasma and deliver results in 10 minutes.
- CPV Ag — Canine Parvovirus Antigen: detects CPV-2 directly in faecal samples. Essential for rapid differentiation of parvo from other haemorrhagic gastroenteritis causes.
- CDV Ag/Ab — Canine Distemper Virus: antigen test for active infection; antibody test for serosurvey and vaccination monitoring.
- CHW Ag — Canine Heartworm Antigen: detects adult female Dirofilaria immitis antigen in whole blood. High sensitivity; suitable for annual screening.
- EHR/ANA/BG/BC Ab — Tick-borne disease panel: simultaneous detection of antibodies to Ehrlichia canis, Anaplasma phagocytophilum, Babesia gibsoni and Borrelia burgdorferi.
- TOXO Ab — Toxoplasma gondii antibody: IgG/IgM detection for toxoplasmosis serodiagnosis.
- Brucella Ab — Brucella canis antibody: reproductive disease screening in breeding kennels.
- CAV-II/CIV Ag — Canine Adenovirus Type 2 / Canine Influenza Virus: respiratory disease panel.
- Canine IgE (Allergy) — Total IgE and allergen-specific panels for atopic dermatitis diagnosis.
Feline Rapid Tests
The Sabervet feline range addresses the major infectious threats in companion cats, including immunosuppressive viruses and common enteric pathogens.
- FPV Ag — Feline Panleukopenia Virus Antigen: detects feline parvovirus in faeces. Cross-reactive with CPV-2.
- FeLV Ag — Feline Leukaemia Virus Antigen: detects p27 core antigen; essential for all new cat intakes and sick cat workups.
- FIV Ab — Feline Immunodeficiency Virus Antibody: detects anti-FIV IgG; key for chronic disease workups and pre-blood-donor screening.
- FIPV Ag/Ab — Feline Infectious Peritonitis Virus: both antigen and antibody formats available.
- FHV/FCV Ag — Feline Herpesvirus / Calicivirus: upper respiratory tract infection panel.
Porcine Rapid Tests
Rapid on-farm diagnosis of swine diseases enables immediate biosecurity decisions and reduces diagnostic delay between outbreak detection and intervention.
- CSFV Ag/Ab — Classical Swine Fever (Hog Cholera): both antigen and antibody tests; critical for outbreak investigation and OIE-listed disease surveillance.
- PRRSV Ag/Ab — Porcine Reproductive and Respiratory Syndrome Virus: one of the most economically significant swine pathogens globally. Both European and North American strains covered.
- ASFV Ag/Ab — African Swine Fever Virus: antigen and antibody detection for the OIE-listed transboundary disease causing severe global economic losses.
- PCV2 Ag — Porcine Circovirus Type 2: associated with postweaning multisystemic wasting syndrome (PMWS).
- PRV (Aujeszky’s Disease) Ab — gE antibody for differentiating vaccinated from field-infected pigs (DIVA).
Bovine Rapid Tests
Cattle diagnostics span reproductive management, respiratory disease and notifiable pathogens.
- Bovine Pregnancy (PAG) — Pregnancy-associated glycoprotein detection in milk or blood; early pregnancy diagnosis from day 28 post-service.
- BoCV Ag — Bovine Coronavirus Antigen: faecal test for neonatal calf diarrhoea workup.
- BRD Panel (BRSV/BPI3/BCV/BVDV) — Bovine Respiratory Disease complex multiplex rapid test.
- Brucella Ab — Brucella abortus antibody for herd surveillance.
- FMD Ag — Foot and Mouth Disease Virus Antigen: pen-side test for this OIE-listed priority pathogen.
Avian / Poultry Rapid Tests
Poultry rapid tests are designed for pen-side use on tracheal/cloacal swab eluates, enabling same-day flock-level decisions.
- AIV H5 Ag / H7 Ag / H9 Ag — Avian Influenza Virus subtype-specific antigen tests. H5 and H7 are OIE-listed; H9 is the most prevalent low-pathogenicity strain in Asia.
- NDV Ag — Newcastle Disease Virus Antigen: key for differential diagnosis of respiratory and neurological signs in poultry.
- IBV Ag — Infectious Bronchitis Virus: respiratory tract pathogen causing severe production losses.
- IBDV Ag — Infectious Bursal Disease (Gumboro Disease): immunosuppressive virus in young chickens.
- CAV Ag — Chicken Anaemia Virus: immunosuppressive pathogen, important in broiler and layer flocks.
The Technology Advantage: Why Colloidal Gold LFIA for Veterinary Diagnostics?
Compared to conventional laboratory methods — ELISA, PCR, virus isolation, serum neutralisation — colloidal gold LFIA offers decisive practical advantages in field veterinary settings:
| Parameter | LFIA Rapid Test (Sabervet) | Laboratory ELISA | PCR |
|---|---|---|---|
| Time to result | 5–15 minutes | 2–4 hours | 4–8 hours |
| Equipment required | None | Plate reader, washer, pipettes | Thermocycler, gel system |
| Sample types | Whole blood, serum, faeces, swab eluate | Serum/plasma | Tissue, swab, blood |
| Point-of-care use | Yes — clinic, farm, field | No | No |
| Cold chain dependency | 2–30 °C storage | 2–8 °C storage + reagents | −20 °C reagents |
| Cost per test | Low | Medium | High |
| Trained operator required | No | Yes | Yes |
The LFIA format does not replace PCR or ELISA for confirmatory or reference laboratory work. Its clinical value lies in immediate triage: a negative rapid test in a patient with low pre-test probability can confidently rule out certain diseases; a positive in the right clinical context enables same-visit treatment decisions.
Colloidal Gold Nanoparticle Properties and Diagnostic Significance
The optical properties of colloidal gold are fundamental to LFIA performance. Gold nanoparticles exhibit surface plasmon resonance (SPR) — the collective oscillation of conduction electrons when illuminated — producing the intense red/pink colour visible to the naked eye. Key parameters that affect test performance include:
- Particle size (20–40 nm typical): Larger particles produce more intense colour but may reduce conjugation efficiency. Sabervet tests are optimised for maximum visual signal at minimum target analyte concentration.
- Protein conjugation: Antibodies adsorb to gold via electrostatic and hydrophobic interactions at pH near the protein’s isoelectric point. Optimal pH and protein-to-gold ratio are critical manufacturing quality parameters.
- Blocking: BSA or casein is added post-conjugation to block remaining gold surface and prevent non-specific binding — directly affecting test specificity.
- Stability: Properly formulated gold conjugates are stable for 24+ months at 2–30 °C in lyophilised or dried form on the conjugate pad.
Sabervet Manufacturing: ITGen Quality Standards
All Sabervet rapid diagnostic tests are developed and manufactured by ITGen (Hangzhou Antigenne Technology Co., Ltd.), a specialist veterinary IVD manufacturer based in Hangzhou, China. Manufacturing is conducted under:
- ISO 13485 — Medical devices quality management system
- CE marking — European conformity for in vitro diagnostic devices
- GMP-compliant production facilities with Class 10,000 cleanroom membrane processing
- Independent validation of each batch against reference positive and negative panels
Each test kit includes a CE-marked package insert with declared sensitivity, specificity, cross-reactivity data and lot-specific quality control results. Sabervet products are distributed to veterinary practices, diagnostic laboratories and government veterinary services in over 40 countries.
How to Perform a Sabervet Rapid Test: Step-by-Step
- Prepare the sample. Collect the appropriate sample as specified in the package insert (whole blood, serum, plasma, faeces or swab eluate). Allow refrigerated samples to equilibrate to room temperature (18–25 °C) before testing.
- Open the foil pouch. Remove the test cassette from its sealed foil packaging immediately before use. Use within 30 minutes of opening. Do not use a cassette that has been exposed to humidity or has expired.
- Add the sample. Dispense the specified volume of sample (typically 2–10 µL) into the sample well (S) using the dropper or pipette provided.
- Add buffer solution. For most tests, add 2–3 drops of assay buffer immediately after the sample to initiate lateral flow migration.
- Read the result. Interpret the cassette at the time specified in the package insert (typically 10–15 minutes). Do not read after the maximum reading window.
Important: The control line (C) must appear for any result to be valid. A faint test line (T), regardless of intensity, is a positive result. If no C line appears, the test is invalid — repeat with a new cassette from a different lot if invalidity persists.
Clinical Application: Integrating Rapid Tests into the Diagnostic Pathway
Rapid tests deliver maximum clinical value when integrated into a structured diagnostic pathway rather than used in isolation. The following principles apply across all Sabervet tests:
- Pre-test probability matters. A positive result in an animal with classic clinical signs and relevant exposure history carries high positive predictive value. A positive in a vaccinated, clinically healthy animal in a low-prevalence population requires confirmatory testing.
- Antigen tests diagnose; antibody tests surveil. Use Ag tests for acute disease diagnosis. Use Ab tests for vaccination status monitoring, herd serosurveys and screening programmes.
- Combine with clinical examination. Rapid tests support, not replace, the clinical examination. Always interpret results in the context of history, clinical signs, haematology and biochemistry.
- Negative does not exclude disease. In very early infection (pre-antigenaemia or pre-seroconversion), rapid tests may be negative. Repeat testing 5–7 days later or refer for PCR if clinical suspicion remains high.
Frequently Asked Questions
How does a colloidal gold rapid test work?
Colloidal gold rapid tests use lateral flow immunoassay technology. A small sample is applied to the test cassette and migrates along a nitrocellulose membrane by capillary action. Gold nanoparticles conjugated to specific antibodies bind the target analyte and accumulate at the test line, producing a visible coloured band. Results are read visually in 5–15 minutes with no equipment.
Which diseases can Sabervet rapid tests detect?
Sabervet tests cover over 30 pathogens across five animal species. Canine: CPV, CDV, CHW, EHR/ANA/BG/BC, TOXO, Brucella, CIV, FeLV. Feline: FPV, FeLV, FIV, FIPV, FHV/FCV. Porcine: CSFV, PRRSV, ASFV, PCV2, PRV. Bovine: Bovine Pregnancy (PAG), BoCV, BRD panel, Brucella, FMD. Avian: AIV H5/H7/H9, NDV, IBV, IBDV, CAV.
What is the difference between antigen and antibody rapid tests?
Antigen (Ag) tests detect the pathogen itself — viral proteins, bacterial antigens — and are used to diagnose active, current infection. They are most sensitive during the acute phase of illness. Antibody (Ab) tests detect the host’s immune response (IgG and/or IgM) and indicate past or current exposure, vaccination response or chronic infection. Both formats are available within the Sabervet range.
Are Sabervet tests CE-marked and ISO certified?
Yes. All Sabervet rapid diagnostic tests carry CE marking for in vitro diagnostic devices and are manufactured under ISO 13485 quality management systems by ITGen / Hangzhou Antigenne Technology Co., Ltd. Each lot is validated against reference positive and negative panels before release.
Can Sabervet tests be used without laboratory equipment?
Yes. All Sabervet lateral flow tests are fully self-contained and designed for point-of-care use in veterinary clinics, on-farm or in the field. No reader, analyser, centrifuge or additional reagents are required. The test cassette, sample dropper and assay buffer are included in every kit.
What sample types are accepted?
Sample requirements vary by test. Most canine and feline tests accept whole blood (EDTA or heparin), serum or plasma. Enteric disease tests (CPV, FPV, BoCV) use faecal samples or faecal swab eluates. Respiratory disease tests (AIV, NDV, IBV) use tracheal or cloacal swab eluates. Bovine Pregnancy tests accept serum, plasma or milk. Full details are in each test’s package insert.
How should Sabervet test kits be stored?
Store at 2–30 °C in the original sealed foil pouch. Do not freeze. Keep away from direct sunlight, humidity and strong odours. Shelf life is 18–24 months from manufacture date depending on the specific test. Do not use kits beyond the expiry date printed on the foil pouch.
Order Sabervet Rapid Diagnostic Tests
Sabervet rapid tests are available for veterinary clinics, diagnostic laboratories, government veterinary services and authorised distributors worldwide. ITGen supplies direct and through a global distribution network, with competitive MOQ, flexible pack sizes (10, 25 or 50 tests per box depending on the product) and reliable supply chain.
- CE-marked — accepted in EU and international markets
- ISO 13485 manufactured — consistent batch-to-batch quality
- Global distribution — 40+ countries served
- Full portfolio — canine, feline, porcine, bovine and avian in one source
- Technical support — product datasheets, CE certificates and validation data available on request
Browse the full Sabervet product range → | Request samples or a quote
